Fire & Smoke Rated Curtains
Fire curtains are manufactured and produced in accordance with the specification submitted by the Warrington Fire Research Establishment No 169805 and 168906 which relates to BS7346 Fire / Heat criteria.
  • CurtainsFire curtains are formed from a fire rated fabric 0.65mm thick, stitched and hemmed using Kevlar and stainless steel thread, the unique two section bottom rail allows smooth operation of the curtain
  • Barrel:Fire curtains are formed from a fire rated fabric 0.65mm thick, stitched and hemmed using Kevlar and stainless steel thread, the unique two section bottom rail allows smooth operation of the curtain
  • Barrel:Fire curtain barrels are manufactured from mild steel tube. Tube size is dependant on the overall size of the unit and deflection calculated to conform to British Standards. The barrel is mounted on 20mm high speed bearings and is complete with an enclosed tubular motor either 240 volt AC or 24 volt DC.
  • Safety Feature:Gravity or powered fail safe, operable if the supply fails./li>
  • Guides:Fire curtain guides are constructed from 2.5mm mild steel plate in 2 sections, the front section of the guide is removable and allows repairs to be effected without dismantling the door.The guides are slotted for expansion. Fire Curtain Systems provides a wide range of optional ceiling interfaces, designed to conceal the curtain and blend with the aesthetics of the installation. Access hatches are required for service and maintenance.
  • Hood:Gravity or powered fail safe, operable if the supply fails./li>
  • Hood:The fire curtain hood is formed from 1.2mm mild steel plate and is slotted for expansion.
  • End Plates:The fire curtain end plates are formed from 2.5mm plate. The depth of the plate is dependent on the overall height of the unit, the end plate has a formed motor compartment which will be packed with non combustible material.
  • Finishes:The fire curtain is standard grey, the endplates, guides, hood etc., are powder coated RAL 9010 white as standard, other colours are available at an additional cost/li>
  • Operation:Electrically operated 1PH 240 volt AC or 24 volt DC
  • Release Mechanisms:Linked to the fire alarm as standard other means of activation available are fusible link, smoke detector etc.
  • Sizes:Using our overlapping design, with a single continuous bottom rail, the current assessment allows for coverage of areas up to 54 meters, our flexible multiple roller system and continuous bottom rail are ideal for providing fire and smoke protection to large areas.
